Rechargeable Lithium battery 48v 10ah 15ah for 500w ebike scooters akku
Specification 48v 10ah / 15ah
Battery Model | 48V 10AH ; |
Nominal Capacity (AH) | 10ah |
Nominal Voltage (V) | 48V |
Source Resistance (mΩ) | about 40 |
Cell Specification | 18650 2000mah /2500mah or OEM brand cells Samsung/LG/pANASONIC |
Cell Combination | 13S 4P / 13S 5P |
Cell Size | 18650 CELLS PACK 390*110*75mm |
Cell Quantity (parallel*series) | 40 pcs of 2500mah cells / 50 pcs of 2000mah cells |
Discharge Cutoff Voltage (V) | 35.75+/-1V |
Charge Cut-off Voltage (V) | 42V |
Rated Discharge Current (A) | 10Amps |
Instantaneous Maximum Discharge Current (A) | 10Amps |
Maximum Continuous Discharge Current (A) | 10A , 0r oem 15am |
Maximum Continuous Charge Current (A) | 5A |
Charge Mode | CC/CV |
Standard Charge Current (A) | 2A |
Charge Time under Standard Charge Current | 10 |
Fast Charge Current (A) max | 5A |
Charge Time under Fast Charge Current | 4-5 hours |
Charge Temperature Range | -20 – 60 °C |
Discharge Temperature Range | -20 – 60 °C |
Battery Size | 390 *110*75mm |
Battery Net Weight | 4.0 KG |
Battery Gross Weight | 5.5kgs with charger 42V2A |
10Ah, 12Ah, 16Ah, 20Ah, 24V, 36V, 48V are available Customizes shapes, capacity, and voltage are accepted
Features :
Rechargeable Lithium battery 48v 10ah 15ah for 500w ebike scooters akku
Quality guarantee for 1 years
deep cycle 500-800 times
X.L.R Top charging port
2P /4P bottom discharging ports options customized
Working indicators LED light
