Port:Shenzhen, China
Production Capacity:5000 PCS/Wk
Payment Terms:T/T, Western Union, Paypal
Model NO.:FB-RR106
Installation:Packaged
Rechargeable:Chargeable
Trademark:Delongtop
Transport Package:Standard Package
Specification:390*110*76.6mm
Origin:China
HS Code:8507600090
Type:Lithium-Ion Batteries
Usage:Electric Power, Electric Bicycle
Nominal Voltage:36V
Discharge Rate:Medium Discharge Rate
Shape:Square Battery
Electrolyte:Li-ion
48V 20ah Lithium Ion Battery Pack for Electric Bike/ Vehicle
Specification
| Norminal Voltage | 48v |
| Nominal Capacity | 20ah |
| Product name | 48v20ah rear rack lithium electric bicycle battery |
| Features | Lithium ion battery cells 18650, aluminium case, large capacity 20ah, motor 1000w |
| Dimenssion | 150W*80H*365 Lmm |
| Cycle life | more than 1000 times |
| Customized capacity | 10ah, 12ah, 15ah, 17.5ah, 20ah, 25ah, 30ah. OEM/ODM case length and cost increase accordingly |
| Source Resistance (mΩ) | < 40 |
| Cell Specification | 3.7V 2500mAh |
| Cell Combination | 8-paralle, 13-series 13S8P |
| Cell type | 18650 LITHIUM ION BATTERIE CELLS |
| Cell Quantity (parallel*series) | 104 pcs |
| Charge Cutoff Voltage (V) | 54.6V |
| Discharge Cutoff Voltage (V) | 41+/-1V |
| Maximum Continuous Charge Current (A) | 5A |
| Instantaneous Maximum Discharge Current (A) | 40Ah |
| Maximum Continuous Discharge Current (A) | 30Ah |
| Standard Charge Current (A) | 2C |
| Charge Time under Standard Charge Current | 10 HRS |
| Battery Net Weight | 7.0 KGS |
| Battery Gross Weight | 7.5kgs |
| Applications | Widely applied in Electric Bicycle, Electric vehicle, Electric Tricycle, Electric scooter, Electric golf trolley, Electric car, Electric wheelchairs,two wheel vehicles and etc. |
