| Nominal Capacity: | 10 Ah | Nominal Voltage: | 2.4V |
|---|---|---|---|
| Internal Impedence: | ≤0.8mΩ | Operating Votage: | 1.5V-2.8V |
| Dimension: | 33.5*145.75mm | Battery Weight: | 285.0g±10g |
Shengquan 2.4V 10Ah Lithium titanate LTO Battery Cell
The Lithium titanate LTO battery is the safest lithium battery at present. It will not catch fire or explosion under collision, over the charged or short circuit; The 2.4V 10Ah to battery cell has a max pulse charge and discharge current of 10C rate and continuous charge of 4C, discharge of 6C. It also has a wide operating temperature range from -40℃ to 60℃ and can be widely used in high and cold areas, alpine regions, refrigeration storage, etc.
Product Advantages
High safety: no combustion, no explosion
High rate: fast charge and discharge 20C
Long woking life: more than 30000 cycles
Wide working temperature range: -40~60 degree centigrade
Parameters
Item | Parameters |
Nominal Capacity | 10Ah |
Nominal Voltage | 2.4V |
Internal Impedance | ≤0.8mΩ |
Standard Charge Cut-off Voltage | 2.8V |
Standard Discharge Cut-off Voltage | 1.5V |
Maximum Continuous Charge Current | 4C (40A) |
Maximum Continuous Discharge Current | 6C (60A) |
Maximum Pulse Charge/Discharge Current(10s) | 20C (200A) |
Operating Temperature Range | -40~60℃ |
Operating Humidity Range | Humidity: ≤85%RH |
Storage Temperature Range | -5℃~28℃ |
Weight | 285.0g±10g |
Dimension | 33.5*145.75mm |
Cycle Life | 20000times @80%DOD |
