Lithium Titanate Battery 2.4V 15Ah LTO For Car Stereo,Solar Battery

-The LTO prismatic cell 2.3V 15Ah with 20000cycles life,fast charge(up to 10C) and wide working temperature range(-30°C ~ 55°C) ,size is 216*110*13mm .

-It has been mainly used in the power fields of Car stereo,pure electric / hybrid electric vehicles, pure electric / hybrid electric vehicles, electric forklift, special vehicles etc, and the energy storage fields of photovoltaic / wind power generation system, communication base station power supply, household / industrial UPS, energy storage power station etc

Share:
Description
Specifications
Reviews
Description
Products Details


Product name

Lithium Titanate Battery 2.4V 15Ah LTO for Car stereo,solar battery

Discharge Curve at Low Temperature(-20℃)

  Discharge Curve at High Temperature(55℃)

Specification

Item

Parameters

Model

OSN-13110216-LTO15Ah

Materials

LTO

Nominal capacity

15Ah

Nominal voltage

2.4 V

Dimension

216*110*13mm

Prismatic

Weight

652g

Internal Resistance

≤1mΩ

Operating voltage

Charge cut-off voltage

2.75 V

Discharge cut-off voltage

1.5 V

Maximum charge current

5C

Maximum discharge current

10C

Cycle life

20000 times

Operating Thermal Ambient

Charging

-30℃~ 55℃

Discharging

-30℃~ 55℃

Storage Thermal Ambient

Short term

(within 1 month)

-20℃~ 45℃

Short term

(within 1 year)

-20℃~ 20℃

Highlight

  Super long cycle life: over 20,000 times

  Faster charge: 10mins fully charged

  Higher discharge rate: Up to 10C

  Wide working temperature range: -30°C ~ 55°C

  High Safety(No fire, explosion,leakage)
