Specifications 48V 20AH SILVER Fish Battery
Features :
Lithium ion battery Silver fish model design ebike battery 1000w
Quality guarantee for 1 years
deep cycle 500-800 times
X.L.R Top charging port
2P /4P bottom discharging ports options customized
Working indicators LED light
Battery Model | Hot selling Lithium ion ebike bicycle battery Silver fish 48V 20AH |
| Nominal Capacity (AH) | 20ah |
| Nominal Voltage (V) | 48V |
| Source Resistance (mΩ) | about 40 |
| Cell Combination | 18650 cells 2500mah in 13s8p 48v 20ah |
| Cell Size | 18650 CELLS PACK 365/395/425/495MM LENGTH OEM : 20ah 48v 495*115*75mm |
| Cell Quantity (parallel*series) | 104 pcs cells Lithium ion battery 48v 20ah |
| Discharge Cutoff Voltage (V) | 31v+/-1V |
| Charge Cutoff Voltage (V) | 49V / 54.6V OEM batteries |
| Rated Discharge Current (A) | 10A / 12A /15AH /20A/ 25AH |
| Instantaneous Maximum Discharge Current (A) | 20A |
| Maximum Continuous Discharge Current (A) | 20Ah, other 10A / 15A /20A/ 25A /30A oem CUSTOMZIED |
| Maximum Continuous Charge Current (A) | 5A |
| Charge Mode | CC/CV |
| Standard Charge Current (A) | 2A |
| Charge Time under Standard Charge Current | 10 |
| Fast Charge Current (A) max | 5A |
| Charge Time under Fast Charge Current | 4-5 hours |
| Charge Temperature Range | -20 – 60 °C |
| Discharge Temperature Range | -20 – 60 °C |
| Battery Size | 495 length for 20ah 48v; , others OEM 365 /395/ 425 /465/ 495 mm Customized battery 10ah, 15ah, 20ah, 36v /48v |
| Battery Net Weight | 3.25kgs/ 4.0 KG /5KG/6KG OEM Batteries |
| Battery Gross Weight | 8.5KG; OR OEM capacity |
