Product Paramenters
|
Battery Type
|
LIFEPO4
|
|
Rated Capacity
|
138 Ah
|
|
Typical Capacity
|
138 Ah
|
|
Nominal Voltage
|
12.8V
|
|
Charging Voltage
|
15.2±0.2 V
|
|
Voltage at end of Discharge
|
8±0.2 V
|
|
Standard charge
|
Constant Current /Constant Voltage
|
|
Max Charge Current
|
150AH
|
|
Max Discharge Current
|
150AH
|
|
Dimension
|
1056*166*104mm
|
|
Operation Temperature Range
|
Charge 0～45℃（Current＜69A）；-10～0℃（Current＜27.6A）
Discharge-10～55℃
|
|
Storage Temperature Range
|
-20～35℃
|
|
Open-Circuit Voltage
|
12.8±2.0 V
|
|
Electronic wire
|
UL3239 2#
|
