Deep Cycles TSD NTO60180-49Ah Prismatic Cylindrical Composite Titanium Battery Cel

-The LTO Prismatic Battery cell 2.4v 60Ah has 20000 cycles life,fast charge(up to 10C) and wide working temperature range(-50°C ~ 65°C) .

-Size is

H266 mm*W263 mm *T13 mm, weight is 1.75kg .

-It has been widely used for electric vehicles, household&industrial solar storage ,car audio&car start ,UPS etc. Applications .

Products Details

Product name

20000 cycles 2.4v 60Ah LTO Battery Cell

Specification

名称 Name	高性能钛酸锂电池
额定容量 Rated Capacity	60Ah
额定电压 Rated Voltage	2.3V
内阻 Resistance(AC)	<0.5mΩ
重量 Weight	1.75kg
能量密度 Energy Density	≥79Wh/kg
	≥170Wh/L
功率密度 Power Density	1400W/kg
	3200W/L
尺寸 Dimension	厚 T×宽 W×高 H(mm)	13×266×263
放电 Standard Discharging	恒流/截至电压 Constant Current/Cut-off Voltage	1-8C/1.5V
充电 Standard Charging	恒流/截至电压 Constant Current/Cut-off Voltage	1-5C/2.8V
循环寿命 cycle life	>20,000+ cycles at 100% DOD
工作温度 T	-30 ℃—60℃
储存温度 T	-10 ℃— 45℃

Highlights

Compared with traditional AGM/lead acid batteries, LiFePO4 battery/ Lithium iron phosphate batteries are:

Higher safety and stability：non-toxic, non-polluting, no rare earth metals, no explosion, no fire.
Long service life：10 times lifespan extended to 20000-30000 cycles.
1/4 lighter than lead-acid batteries.
The LFP battery can work in a wide temperature range from -20 to +75°C
No memory effect. Can be charged on demand without loss of capacity.
Suitable for RV, ship, home storage, telecommunication (base station battery)
