Customized high power 36v 24ah li ion electric bike battery pack
Overview
The capacity and dimension can customize according to your request.
12V 24V 36V 48V 60V 72V LiFePO4 Battery for Resident Electric Vehicle
(Can replace for the lead acid battery, with the same size of SLA battery)
| 1.Recharge much faster-can be fully charged in 60 minutes |
| 2.Ensure long cycle life-at least 2000 cycles under 100% DOD |
| 3.Low self discharge rate-only 12% rate each year |
| 4.Most green and safe lithium technology-no liquid leakage no pollution |
| 5.Internal cell balance, built-in Integrated BMS (Battery Management System) |
| 6.Safe technology, will not catch fire or explode when being overcharged |
| 7..No memory record ,can use anytime when charge. |
| 8.Built-in automatic protection for over-charge,over-discharge and over-temperature conditions. |
| 9.Up to 60% weight saving for replacement lead acid battery. |
| 10.Usually be connected in parallel as high voltage battery pack |
| Models | Voltage(V) | Nominal Capacity(AH) | Max.charge current(A) | Weight(kg) +/-5% | Dimension(+/-3mm) | Cycle life DOD 100% | ||
| L(mm) | W(mm) | H(mm) | ||||||
| B-LFP12-16 | 12 | 16 | 5 | 2.3 | 168 | 128 | 75 | >2000 |
| B-LFP12-22 | 12 | 22 | 5 | 3 | 168 | 128 | 105 | >2000 |
| B-LFP24-7 | 24 | 7 | 3 | 2.35 | 130 | 95 | 150 | >2000 |
| B-LFP24-10 | 24 | 10 | 5 | 3 | 180 | 80 | 180 | >2000 |
| B-LFP36-10 | 36 | 10 | 5 | 4 | 250 | 80 | 180 | >2000 |
| B-LFP36-16 | 36 | 16 | 8 | 6.95 | 150 | 90 | 300 | >2000 |
| B-LFP48-10 | 48 | 10 | 5 | 6 | 300 | 150 | 100 | >2000 |
| B-LFP48-12 | 48 | 12 | 5 | 7 | 300 | 150 | 100 | >2000 |
| B-LFP48-16 | 48 | 16 | 5 | 8 | 300 | 150 | 100 | >2000 |
| B-LFP48-20 | 48 | 20 | 10 | 9 | 260 | 175 | 180 | >2000 |
| B-LFP12-200 | 12 | 200 | 100 | 23 | 260 | 175 | 180 | >2000 |
| B-LFP12-400 | 12 | 400 | 100 | 45 | 900 | 650 | 130 | >2000 |
| B-LFP24-200 | 24 | 200 | 100 | 45 | 520 | 380 | 290 | >2000 |
| B-LFP48-112 | 48 | 112 | 50 | 66 | 130 | 95 | 150 | >2000 |
| B-LFP48-224 | 48 | 224 | 50 | 112 | 800 | 650 | 120 | >2000 |
| B-LFP72-224 | 72 | 224 | 50 | 168 | 150 | 90 | 300 | >2000 |
