Description

Port:Shenzhen, China

Production Capacity:1000PCS/Week

Payment Terms:T/T, Paypal, Money Gram

Model NO.:FB-RR4820-138P

Rated Capacity:20ah

Standard Voltage:48V

Usage:Remote Control Boat, Remote Control Car, for Electronic Products

Electrolyte:Lithium Iron Phosphate LiFePO4 Battery

Net Weight:8.5kgs/PCS/Carton

Pakcgae:One Pieces in One Carton

Cpacity:20ah

Voltage:48V

Application:Ebike, Bicycles, Scooters, EV Bikes, Golf Cart

Combination:13s8p 18650 Battery Cell with BMS

BMS:20ah

Standard Charging Current:14.6V 20ah

Continous Discharging Current:20A

Product:18650 Lithium Li-ion Rear Rack Type Electric Bike

Trademark:DeLong or OEM

Transport Package:Standard Export Package

Specification:495*150*80 mm

Origin:China

HS Code:8507600090

Type:Lithium-Ion Battery Pack

Connection Mode:Series and Parallel

Rechargeable:Chargeable

Discharge Rate:Medium Discharge Rate

Size:Medium

Accessories Type:Battery



 specifications

18650 lithium li-ion rear rack type electric bike battery 48v 20ah



ModelRear LI-ION Ebike Battery pack 48v20Ah 13S8P 2500mAh
 DL-RR4820-13S8PBattery materiallithium ion battery
Typical voltage48V or customerizedRated capacity 20ah or customerized
DimensionscustomerizedInner impedanceles than 100mΩ
Full voltage29.4VMax charge current4A
Discharge cut-off voltage54.6VRated dicharge current5A
Max discharge current20ACharge methods CC/CV
Battery weight 3.5KgOver-current protection current 25A
Cylce life More than 500-1000 timesCharging temperature 0-45 degree
Ceftified by CE,UL,ROHS,SGS etc.Discharging temperature-20-60 degree
Expecting driving distancemore than 50KM( 350w Motor) Charging port: LotusDischarging port: Anderson
 Charger Specification
AC input 100-240V 50/60HZDC Output54.6V 2A
Size395*150*80mm can be customizedCharging time around6-7 hours
