| Nominal Capacity: | 200Ah | Nominal Voltage: | 12V |
|---|---|---|---|
| Internal Impedence: | Operating Votage: | ||
| Dimension: | 522*239*218 | Battery Weight: | 26.3Kg±50g |
Product Description
Battery Features
High Energy Density
High capacity
Long Cycle Life
Discharge stability
Good consistency
Safe and convenient
Fast charging and discharging rate
Applications
Solar system
Energy storage (ESS)
Electric bus
Golf carts
RV
Battery dimension
Parameters
Capacity (min.) | 200Ah |
Nominal Voltage | 12.8V |
Weight | 26.3Kg±50g |
Maximum Charging voltage | (14.6±0.05)V |
Cutoff Discharge Voltage | 8.8V（cell：2.2V） |
Standard Charge Current Rate | 0.3C |
Standard Discharge Current | 1C |
Max Continuous Charging Current | 0.5C(100A) |
Max Continuous Discharging Current | 1C(200A) |
Max Peak Discharging Current | 1.5C 300A (5 s) |
Charging Time | ≈3h（@0.3C） |
Efficiency | ≥96% |
Length | 522mm |
Width | 239mm |
Height | 218mm |
Charging Temperature | 0~60℃ |
Discharging Temperature | -20-60℃ |
BMS | Yes |
Communication | Bluetooth |
